JHC Telescopic Handler Hydraulic Mechanical Transmission Power Steering

Name: JHC Telescopic Handler Hydraulic Mechanical Transmission Power Steering
Brand: JIANGHE (JHC)
Price: 1 USD

Place of Origin : Henan, China (Mainland)

Brand Name : JIANGHE (JHC)

Certification : CE ISO9001 SGS

Model Number : T3507

Supply Ability : 300 Unit/Units per Month

Packaging Details : standard export package/container

MOQ : 1 Unit/Units

Price : Negotiable

Lift Mechanism : Telehandler

Lift Drive / Actuation : Electric Motor

Power : Cummins 99P(73KW)

Rated Loading Capacity : 3500KG

Min. Lifting Height : 2.51m

Max. Lifting Height : 7.15m

Overall Dimensions : 5m*2.35m*2.51m(L*W*H)

Weight : 7.95t

Color : Blue&Grey

Power source : Commins QSF3.8 99HP

After-sales Service Provided : Overseas third-party support available

Warranty : 2 Years

Port : TIANJIN/QINGDAO/SHANGHAI

Contact Now

Product Description

Product Application

T3507 telescopic forklifts come with four-wheel drive and rigid suspension. The telehandlers provide hydraulic-me-chanical transmission, hydraulic power steering, hydraulic braking and rear-wheel steering. The two-stage quadrilateral telescopic boom serves as the working unit. The fork of a regular forklift is equipped with a side shifter. In addition, arrange of options including such accessories as the bucket, lifting hook, and boom, etc. are available to customers. The telescopic forklift offers better performance than a general fork truck in terms of the handling height and cross-country ability. The telescopic forklift is applicable to the unstuffing and casing of pellatized goods in containers, as well as handling, stacking and short-distance transportation of a variety of packaged goods. The forklift, suitable for many different working environments, is ideal equipment for loading and unloading, lifting, and transportation in mining, factory, architecture, building material, dock, municipal ngineering industries, and more.

SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR
Engine	Engine model	Kw/rpm	135.5/2150
	No. of cylinders	Kw/rpm	637/1800
	Net Power	L	6.494
Main performance parameters	Main performance parameters	km/h	5.9/4.0
	Travel speed (max. & min.)	°	<=35
	Max. Gradeability	rpm	11.3
Hydraulic system	Hydraulic system	KPa	50.1
	Main pump	KN	161
	Rate flow	KN	125

JHC Telescopic Handler Hydraulic Mechanical Transmission Power Steering

Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Certifications

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	4.995m (L) * 2.35m (W) * 2.51 (H)
Weight
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
